Description
General
Economical, Reliable Potentiostat For 1-Channel DC Experiments
Squidstat Solo Performance Summary
| Max Current Per Channel | ±100 mA |
| Potential Scan Range | ±10 V |
| Measured Current | 0.004% of range, |
| Resolution | down to 400 pA |
| Potential Resolution | 300 µV |
| Temporal Resolution | 1 ms |
| Channels Per Unit | 1, DC-only |
| Dimensions | 22 x 16 x 8 cm, 1 kg |
| Works with RRDE? | Yes, with 2-3 units |
Squidstat Solo Highlights:
- Top quality single-channel functionality with a compact design
- Lowest-priced commercially available potentiostat with a computer interface
- Multiple units can run simultaneously with other Squidstat models
- Onboard memory automatically backs up all channel data for future recovery
Includes free software and unlimited remote technical support
General
| Operating Modes | Potentiostat, Galvanostat, ZRA |
| Cell Connections | 2, 3, 4, of 5 electrode |
| Temporal Resolution | 1 ms |
| Floating vs. Earth-grounded | Earth-grounded via USB-to-computer |
| Input Impedance | 5 GOhm (typical) |
| Input Bias Current | 5 pA (typical) |
| Onboard Memory | 16 GB for automatic data backup |
| Dimensions | 22 cm x 16 cm x 8 cm |
| Weight | 1 kg |
| Computer Interface Connection | 1 USB port, PC or Mac compatible |
| Power Requirements | 110-120 VAC or 220-240 VAC, 50-60 Hz |
